1. 5/8″ 90-degree copper elbow : CLR-019
This product is a 1. 5/8″ 90-degree copper elbow, model number ACLR-019
Technical Specifications
- Model Number: CLR-019.
- Material: Wrought copper (typically ASTM B75 Alloy C12200), which is lead-free and offers high thermal conductivity and corrosion resistance.
- Dimensions:
- Nominal Size: 1 5/8 inches.
- Actual Inner Diameter (ID): Designed for 1 5/8″ outer diameter (OD) copper tubing.
- Design: A 90-degree long-radius bend. This sweeping design is engineered to minimize flow resistance and pressure drop, which is critical for high-volume systems.
- Connection: Solder/sweat joint (Cup x Cup), requiring professional brazing or soldering for a permanent, leak-proof seal.
Description
Description
This product is a 1 5/8″ 90-degree copper elbow, model number CLR-019
Technical Specifications
- Model Number: CLR-019.
- Material: Wrought copper (typically ASTM B75 Alloy C12200), which is lead-free and offers high thermal conductivity and corrosion resistance.
- Dimensions:
- Nominal Size: 1 5/8 inches.
- Actual Inner Diameter (ID): Designed for 1 5/8″ outer diameter (OD) copper tubing.
- Design: A 90-degree long-radius bend. This sweeping design is engineered to minimize flow resistance and pressure drop, which is critical for high-volume systems.
- Connection: Solder/sweat joint (Cup x Cup), requiring professional brazing or soldering for a permanent, leak-proof seal.
