high-capacity multi-function rotary switch : RS-035
This is a high-capacity multi-function rotary switch, specifically model RS-35, used for regulating complex electrical circuits in large household appliances like ovens and stoves. Despite the “Door Switch” label in the image, its design is that of a multi-position function selector.
Technical Specifications
Based on the image details and industry standards for the AFTC-RS series:
- Model Number: RS-35.
- Electrical Rating: Typically 16A at 250V AC. This heavy-duty rating allows it to safely manage the high current required by multiple heating elements (top, bottom, grill, and convection) and fans.
- Temperature Rating: T150. This indicates the component is engineered to operate in high-heat environments up to 150°C (302°F).
- Pin Configuration: This is a high-pin count model (appearing to have 11 to 12 terminals per side). It is used in advanced appliances that feature numerous cooking modes, requiring complex internal switching.
- Shaft Design: Features a durable metal D-shaped shaft, ensuring a secure fit for the control knob and preventing slippage during rotation.
- Construction: The body is made from flame-retardant bakelite (phenolic resin) to provide high electrical insulation and thermal stability.
Description
Description
This is a high-capacity multi-function rotary switch, specifically model RS-35, used for regulating complex electrical circuits in large household appliances like ovens and stoves. Despite the “Door Switch” label in the image, its design is that of a multi-position function selector.
Technical Specifications
Based on the image details and industry standards for the AFTC-RS series:
- Model Number: RS-35.
- Electrical Rating: Typically 16A at 250V AC. This heavy-duty rating allows it to safely manage the high current required by multiple heating elements (top, bottom, grill, and convection) and fans.
- Temperature Rating: T150. This indicates the component is engineered to operate in high-heat environments up to 150°C (302°F).
- Pin Configuration: This is a high-pin count model (appearing to have 11 to 12 terminals per side). It is used in advanced appliances that feature numerous cooking modes, requiring complex internal switching.
- Shaft Design: Features a durable metal D-shaped shaft, ensuring a secure fit for the control knob and preventing slippage during rotation.
- Construction: The body is made from flame-retardant bakelite (phenolic resin) to provide high electrical insulation and thermal stability.
