4-Pin Oven switch : RS- 005
The provided image details the RS-005, a heavy-duty dual rocker switch designed for high-current applications in household appliances.
Technical Specifications
Based on the image markings and standard industry data for this model:
- Model Number: RS-005
- Electrical Rating: 32 Amps (32A), though similar industrial rockers often carry standard ratings of 16A to 20A at 250V AC.
- Pin Configuration: 4-Pin layout (commonly 2 independent circuits).
- Switch Type: Double Pole Single Throw (DPST), ON-OFF functionality.
- Mounting: Snap-in panel mounting, likely fitting a standard cutout of approximately 30mm x 22mm.
- Housing: Black nylon (UL 94V-2 flame retardant) with two independent red actuators.
Description
Description
The provided image details the RS-005, a heavy-duty dual rocker switch designed for high-current applications in household appliances.
Technical Specifications
Based on the image markings and standard industry data for this model:
- Model Number: RS-005
- Electrical Rating: 32 Amps (32A), though similar industrial rockers often carry standard ratings of 16A to 20A at 250V AC.
- Pin Configuration: 4-Pin layout (commonly 2 independent circuits).
- Switch Type: Double Pole Single Throw (DPST), ON-OFF functionality.
- Mounting: Snap-in panel mounting, likely fitting a standard cutout of approximately 30mm x 22mm.
- Housing: Black nylon (UL 94V-2 flame retardant) with two independent red actuators.
