Samsung washing machines Inlet Valve : IV-025
This image provides the technical specifications for the IV-025 Washing Machine Inlet Valve, a genuine replacement part primarily designed for Samsung appliances.
🔍 Technical Specifications
- Model Number: IV-025
- Manufacturer Part Number: DC62-00233K (Compatible with DC62-00233B/C/D/H/J)
- Valve Type: 3-Way Solenoid Water Inlet Valve
- Voltage: DC 12V (Direct Current)
- Pin Configuration: 6.3 Pins (Standard spade terminal size)
- Function: An electromechanical component that opens to regulate water flow into the machine drum during wash and rinse cycles.
⚙️ Compatibility & Usage
- Main Application: Specifically engineered for Samsung front-loading washing machines (e.g., model WD70TA046BX), as well as certain Samsung tumble dryers and dishwashers.
- Common Repairs: Used to resolve issues where the machine is not filling with water, is leaking from the back, or is making loud vibrating noises during the water intake phase.
- Installation: Features a specialized bracket for a secure fit within the appliance chassis and three independent solenoid coils to manage different water paths.
Description
Description
This image provides the technical specifications for the IV-025 Washing Machine Inlet Valve, a genuine replacement part primarily designed for Samsung appliances.
🔍 Technical Specifications
- Model Number: IV-025
- Manufacturer Part Number: DC62-00233K (Compatible with DC62-00233B/C/D/H/J)
- Valve Type: 3-Way Solenoid Water Inlet Valve
- Voltage: DC 12V (Direct Current)
- Pin Configuration: 6.3 Pins (Standard spade terminal size)
- Function: An electromechanical component that opens to regulate water flow into the machine drum during wash and rinse cycles.
⚙️ Compatibility & Usage
- Main Application: Specifically engineered for Samsung front-loading washing machines (e.g., model WD70TA046BX), as well as certain Samsung tumble dryers and dishwashers.
- Common Repairs: Used to resolve issues where the machine is not filling with water, is leaking from the back, or is making loud vibrating noises during the water intake phase.
- Installation: Features a specialized bracket for a secure fit within the appliance chassis and three independent solenoid coils to manage different water paths.
