ZYD-2J-6-H. 220V. 6.5W. REF. Evaporator Fan Motor. RM-018
Based on the image provided, here are the full details for the Refrigerator Evaporator Fan Motor (220V Version).
Technical Specifications
- Model Number: RM-018 (Ref: ZYD-2J-6-H)
- Voltage: 220V AC
- Power Output: 6.5 Watts
- Current: 0.05 Amps
- Frequency: 50/60 Hz
- Origin: Made in China
Physical Features
- Motor Type: Heavy-duty shaded-pole AC induction motor.
- Design: Circular silver motor body mounted within a sturdy black C-frame housing.
- Shaft: Features a single long, smooth shaft designed for a press-fit plastic fan blade.
- Mounting: Integrated black plastic mounting bracket with four corner holes and a gray plastic lower support frame for vibration reduction.
- Wiring: Includes blue and white insulated wire leads with a 2-pin white plastic connector for a secure “plug-and-play” installation.
Primary Application
- Refrigerator Cooling: Specifically used as an evaporator fan motor to pull cold air from the freezer coils and distribute it throughout the unit. It is a universal-style replacement for many “No-Frost” refrigerator models.
Description
Description
Based on the image provided, here are the full details for the Refrigerator Evaporator Fan Motor (220V Version).
Technical Specifications
- Model Number: RM-018 (Ref: ZYD-2J-6-H)
- Voltage: 220V AC
- Power Output: 6.5 Watts
- Current: 0.05 Amps
- Frequency: 50/60 Hz
- Origin: Made in China
Physical Features
- Motor Type: Heavy-duty shaded-pole AC induction motor.
- Design: Circular silver motor body mounted within a sturdy black C-frame housing.
- Shaft: Features a single long, smooth shaft designed for a press-fit plastic fan blade.
- Mounting: Integrated black plastic mounting bracket with four corner holes and a gray plastic lower support frame for vibration reduction.
- Wiring: Includes blue and white insulated wire leads with a 2-pin white plastic connector for a secure “plug-and-play” installation.
Primary Application
- Refrigerator Cooling: Specifically used as an evaporator fan motor to pull cold air from the freezer coils and distribute it throughout the unit. It is a universal-style replacement for many “No-Frost” refrigerator models.
